Initial Setting Level Section 5-9
Note Even when control output 1 or control output 2 is used as a control output or a
simple transfer output, 0 to 20 mA can be used.
■ Related Parameter
Transfer output type (initial setting level): Page 235
The Bank Numbers Used parameter is used when switching bank numbers
according to ON/OFF combinations of event inputs that have been preset for
bank numbers 0 to 7. The number of banks used can be changed to 2, 4, or 8,
according to the set value.
The Event Input Assignment Screen will not be displayed when event inputs
are assigned for the Bank Numbers Used parameter. The following tables
show the set values and the display/hide status of Event Input Assignments 1
and 2.
■ Controllers with Event Inputs 1 and 2 (Two Event Inputs)
■ Controllers with Event Inputs 3 and 4 (Two Event Inputs)
■ Controllers with Event Inputs 1 to 4 (Four Event Inputs)
Linear current
output
Default
4-20: 4 to 20 mA
0-20: 0 to 20 mA
4-20
Setting
See
See
ev-b Bank Numbers Used
Event inputs must be supported.
Function
Event Input Assignment 1 Event Input Assignment 2
Bank Num-
bers Used
0 Displayed (Banks not switched.)
1 Hidden (2 banks) Displayed (Event input 2 not
used to switch banks.)
2 Hidden (4 banks)
Event Input Assignment 3 Event Input Assignment 4
Bank Num-
bers Used
0 Displayed (Banks not switched.)
1 Hidden (2 banks) Displayed (Event input 4 not
used to switch banks.)
2 Hidden (4 banks)
Event Input
Assignment
1
Event Input
Assignment
2
Event Input
Assignment
3
Event Input
Assignment
4
Bank Numbers
Used
0 Displayed (Banks not switched.)
1 Hidden (2
banks)
Displayed (Event inputs 2 to 4 not used to
switch banks.)
2 Hidden (4 banks) Displayed (Event inputs 3 to
4 not used to switch banks.)
3 Hidden (8 banks) Displayed
(Event input 4
not used to
switch
banks.)
