Omron E5AN-H User Manual

235
Initial Setting Level Section 5-9
• This parameter sets the transfer output type.
• The following table shows the differences between models with a transfer
output and models without a transfer output that use control output 1 or
control output 2 as a simple transfer output.
■ Transfer Output Destination
■ Precision and User Calibration
Note For details on the calibration method, refer to SECTION 6 CALI-
BRATION.
]
■ Related Parameter
Transfer output upper limit, Transfer output lower limit (initial setting level):
Page 236
tr-t Transfer Output Type
There must be a transfer output, cur-
rent output, or linear voltage output.
Transfer
output
Control output 1 Control output 2 Transfer output
destination
Yes --- --- Transfer output
No Current output or
linear voltage out-
put
No
Relay output, voltage
output (for driving SSR),
or SSR output
Control output 1
No Current output or
linear voltage out-
put
Current output or linear
voltage output
Control output 1
No Relay output, volt-
age output (for
driving SSR), or
SSR output
Current output or linear
voltage output
Control output 2
No Relay output, volt-
age output (for
driving SSR), or
SSR output
No
Relay output, voltage
output (for driving SSR),
or SSR output
No
Precision User calibration
Transfer output ±0.3% FS Supported. (See note.)
Simple transfer output Not specified. Not supported.
Transfer output type Default
OFF off off
Set point sp
Set point during SP ramp sp-m
PV pv
MV monitor (heating) mv
MV monitor (cooling) c-mv
Valve opening v-m
Setting
