234
Initial Setting Level Section 5-9
• Select one of the following five alarm 3 types:
Deviation, deviation range, absolute value, PV change rate alarm, or RSP
alarm.
Refer to the alarm 1 type list. The 12: LBA (Loop Burnout Alarm) setting in
that list cannot be used.
■ Related Parameters
Bank * alarm value 3: Page 213, Bank * alarm value upper limit 3, Bank *
alarm value lower limit 3: Page 214 (operation level)
Standby sequence reset: Page 244, Auxiliary output * open in alarm: Page
245, Alarm 3 hysteresis: Page 233, Alarm 3 latch: Page 250 (advanced func-
tion setting level)
alt3 Alarm 3 Type
Alarm 3 must be assigned.
Setting
See
See
