Initial Setting Level Section 5-9
• These parameters set the hysteresis for alarms 1, 2, and 3.
■ Related Parameters
Bank * alarm value 1 to 3: Page 211, 212, 213, Bank * alarm value upper limit
1 to 3, Bank * alarm value lower limit 1 to 3: (bank setting level): Page 212,
213, 214
Alarm 1 to 3 type (initial setting level): Page 231, 233, 234
Standby sequence reset: Page 244, Alarm 1 to 3 open in alarm: Page 250,
Alarm 1 to 3 latch: Page 250 (advanced function setting level)
• Select one of the following five alarm 2 types: Deviation, deviation range,
absolute value, PV change rate alarm, or RSP alarm.
Refer to the alarm 1 type list. The 12: LBA (Loop Burnout Alarm) setting in
that list cannot be used.
■ Related Parameters
Bank * alarm value 2: Page 212
Bank * alarm value upper limit 2, Bank * alarm value lower limit 2 (bank setting
level): Page 213
Standby sequence reset: Page 244, Auxiliary output 2 open in alarm: Page
245, Alarm 2 hysteresis: Page 233
Alarm 2 latch (advanced function setting level): Page 250
alh1 Alarm 1 Hysteresis
Alarm 1 must be assigned.
The alarm 1 type must not be 0, 12,
or 13.
alh2 Alarm 2 Hysteresis
Alarm 2 must be assigned.
The alarm 2 type must not be 0, 12,
or 13.
alh3 Alarm 3 Hysteresis
Alarm 3 must be assigned.
The alarm 3 type must not be 0, 12,
or 13.
Models Unit Default
Temperature input: 0.1 to
3,240.0
°C or °F 0.2
Analog input: 0.01 to 99.9 %FS 0.02
Function
Setting
See
See
alt2 Alarm 2 Type
Alarm 2 must be assigned.
Function
Setting
See
See
