Omron E5AN-H User Manual

214
Bank Setting Level Section 5-5
• During temperature input, the decimal point position is set automatically
according to the current sensor, and during analog input it depends on the
Decimal Point parameter setting.
■ Related Parameters
Input type: Page 224
Scaling upper limit, Scaling lower limit, Decimal point: Page 226
Alarm 3 type (initial setting level): Page 234
Standby sequence reset: Page 244
Auxiliary output * open in alarm: Page 245
Alarm 3 hysteresis: Page 233
Alarm 3 latch (advanced function level): Page 250
These parameters set the alarm value upper and lower limits individually for
each bank when the mode for setting the upper and lower limits is selected for
the Alarm 3 Type parameter (initial setting level).
• These parameters set the upper and lower limits of alarm 3 for banks 0 to
7.
• During temperature input, the decimal point position is set automatically
according to the current sensor, and during analog input it depends on the
Decimal Point parameter setting.
■ Related Parameters
Input type: Page 224
Scaling upper limit, Scaling lower limit, Decimal point: Page 226
Alarm 3 type (initial setting level): Page 234
Standby sequence reset: Page 244
Auxiliary output * open in alarm: Page 245
Alarm 3 hysteresis: Page 233
Alarm 3 latch (advanced function level): Page 250
Setting range Unit Default
−19999 to 32400 EU 0.0
Settin
g
See
See
*.a3h Bank * Alarm Value Upper Limit 3
Alarm 3 must be assigned.
*.a3l
Bank * Alarm Value Lower Limit 3
(*: 0 to 7)
The alarm 3 type must be set to
"upper and lower limit alarm,"
"upper and lower limit range alarm,"
or "upper and lower limit alarm with
standby sequence."
Setting range Unit Default
−19999 to 32400 EU 0.0
Function
Settin
g
See
See
