Note (1) The parameters in the current PID set will be accessed.
(2) Displayed for ON/OFF control.
(3) The setting range depends on whether control output 1 is a linear output (relay output, current out-
put, or linear voltage output) or an ON/OFF output (voltage output (for driving SSR) or SSR output.
(4) The setting range depends on whether control output 2 is a linear output (relay output, current out-
put, or linear voltage output) or an ON/OFF output (voltage output (for driving SSR) or SSR output.
(5) This setting is ignored if the Program Pattern parameter is OFF.
(6) WR1 to WR8 are not displayed if logic operations are not used.
Protect Level
Communications Setting Level
Note (1) When setting CWF, either CompoWay/F or SYSWAY can be used as the communications protocol.
(CompoWay/F and SYSWAY are automatically identified by the command frames.)
Parameters Characters Setting (monitor) value Display Default Unit Set value
Move to Protect level pmov −1999 to 9,999 0 None
Operation/Adjust-
ment Protect
oapt 0 to 3 0 None
Initial Setting/Com-
munications Protect
icpt 0 to 2 0 None
Setting Change Pro-
tect
wtpt OFF, ON off, on OFF None
PF Key Protect pfpt OFF, ON off, on OFF None
Parameter Mask
Enable
pmsk OFF, ON off, on ON None
Password to Move to
Protect Level
prlp −1999 to 9,999 0 None
Parameters Characters Setting (monitor) value Display Default Unit Set value
Protocol Setting psel CompoWay/F (SYSWAY),
Modbus (See note 1.)
cwf, mod Compo-
Way/F
(SYSWAY)
None
Communications
Unit No.
u-no 0 to 99 1 None
Communications
Baud Rate
bps 1.2, 2.4, 4.8, 9.6, 19.2, 38.4,
or 57.6
1.2, 2.4,
4.8, 9.6,
19.2, 38.4,
57.6
9.6 kbps
Communications
Data Length
len 7, 8 7 Bit
Communications
Stop Bits
sbit 1, 2 2 Bit
Communications
Parity
prty None, Even, Odd none,
even, odd
Even None
Send Data Wait
Time
sdwt 0 to 99 20 ms
