Sensor Input Setting Range, Indication Range, Control Range
• The default is 5.
• The applicable standards for each of the above input ranges are as follows:
K, J, T, E, N, R, S, B: JIS C1602-1995, IEC 584-1
L: Fe-CuNi, DIN 43710-1985
U: Cu-CuNi, DIN 43710-1985
W: W5Re/W26Re, ASTM E988-1990
JPt100: JIS C 1604-1989, JIS C 1606-1989
Pt100: JIS C 1604-1997, IEC 751
PLII: According to Platinel II Electromotive Force Table by Engelhard Corp.
Input type Specific
ations
Set
value
Input setting range Input indication range
Resistance
thermometer
Pt100 0 −200.0 to 850.0 (°C)/−300.0 to 1,500.0 (°F) −220.0 to 870.0 (°C)/−340.0 to 1,540.0 (°F)
1 −199.9 to 500.0 (°C)/−199.9 to 900.0 (°F) −199.9 to 520.0 (°C)/−199.9 to 940.0 (°F)
2 0.0 to 100.0 (°C)/0.0 to 210.0 (°F) −20.0 to 120.0 (°C)/−40.0 to 250.0 (°F)
JPt100 3 −199.9 to 500.0 (°C)/−199.9 to 900.0 (°F) −199.9 to 520.0 (°C)/−199.9 to 940.0 (°F)
4 0.0 to 100.0 (°C)/0.0 to 210.0 (°F) −20.0 to 120.0 (°C)/−40.0 to 250.0 (°F)
Thermocou-
ple
K
5 −200.0 to 1,300.0 (°C)/−300.0 to 2,300.0
(°F)
−220.0 to 1,320.0 (°C)/−340.0 to 2,340.0
(°F)
6 −20.0 to 500.0 (°C)/0.0 to 900.0 (°F) −40.0 to 520.0 (°C)/−40.0 to 940.0 (°F)
J7−100.0 to 850.0 (°C)/−100.0 to 1,500.0 (°F) −120.0 to 870.0 (°C)/−140.0 to 1,540.0 (°F)
8 −20.0 to 400.0 (°C)/0.0 to 750.0 (°F) −40.0 to 420.0 (°C)/−40.0 to 790.0 (°F)
T9−200.0 to 400.0 (°C)/−300.0 to 700.0 (°F) −220.0 to 420.0 (°C)/−340.0 to 740.0 (°F)
10 −199.9 to 400.0 (°C)/−199.9 to 700.0 (°F) −199.9 to 420.0 (°C)/−199.9 to 740.0 (°F)
E11−200.0 to 600.0 (°C)/−300.0 to 1,100.0 (°F) −20.0 to 620.0 (°C)/−40.0 to 1,140.0 (°F)
L12−100.0 to 850.0 (°C)/−100.0 to 1,500.0 (°F) −120.0 to 870.0 (°C)/−140.0 to 1,540.0 (°F)
U13−200.0 to 850.0 (°C)/−300.0 to 700.0 (°F) −220.0 to 420.0 (°C)/−340.0 to 740.0 (°F)
14 −199.9 to 400.0 (°C)/−199.9 to 700.0 (°F) −199.9 to 420.0 (°C)/−199.9 to 740.0 (°F)
N15−200.0 to 1,300.0 (°C)/−300.0 to 2,300.0
(°F)
−220.0 to 1,320.0 (°C)/−340.0 to 2,340.0
(°F)
R 16 0.0 to 1,700.0 (°C)/0.0 to 3,000.0 (°F) −20.0 to 1,720.0 (°C)/−40.0 to 3,040.0 (°F)
S 17 0.0 to 1,700.0 (°C)/0.0 to 3,000.0 (°F) −20.0 to 1,720.0 (°C)/−40.0 to 3,040.0 (°F)
B 18 100.0 to 1,800.0 (°C)/300.0 to 3,200.0 (°F) 0.0 to 1,820.0 (°C)/0.0 to 3,240.0 (°F)
W 19 0.0 to 2,300.0 (°C)/0.0 to 3,200.0 (°F) −20.0 to 2,320.0 (°C)/−40.0 to 270.0 (°F)
PLII 20 0.0 to 1,300.0 (°C)/0.0 to 2,300.0 (°F) −20.0 to 1,320.0 (°C)/−40.0 to 2,340.0 (°F)
K21−50.0 to 200.0 (°C)/−50.0 to 200.0 (°F) −90.0 to 220.0 (°C)/−90.0 to 240.0 (°F)
J22−50.0 to 200.0 (°C)/−50.0 to 200.0 (°F) −90.0 to 220.0 (°C)/−90.0 to 240.0 (°F)
T23−50.0 to 200.0 (°C)/−50.0 to 200.0 (°F) −90.0 to 220.0 (°C)/−90.0 to 240.0 (°F)
Resistance
thermometer
Pt100 24 −50.0 to 200.0 (°C)/−50.0 to 200.0 (°F) −90.0 to 220.0 (°C)/−90.0 to 240.0 (°F)
Current input 4 to
20 mA
25 Any of the following ranges, by scaling:
−19,999 to 32,400
−1,999.9 to 3,240.0
−199.99 to 324.00
−19.999 to 32.400
−5% to 105% of setting range.
The display shows
−19,999 to 32,400 (numeric range with
decimal point omitted).
0 to
20 mA
26
Voltage input 1 to 5 V 27
0 to 5 V 28
0 to 10 V 29
