55
Setting Output Specifications Section 3-5
Initial Setting Level
3. Press the U Key to set the parameter to h-c.
Note The following output assignments do not need to be set because they
are set automatically by changing the control mode, but they are
shown here as a reference for checking the assignments for each out-
put.
4. Select the Move to Advanced Function Setting Level parameter by press-
ing the M Key. (For details on moving between levels, refer to 4-8 Moving
to the Advanced Function Setting Level.)
Advanced Function Setting Level
5. Press the D Key to enter the password (“−169”), and move from the initial
setting level to the advanced function setting level.
Advanced Function Setting Level
6. Select the Control Output 1 Assignment parameter by pressing the M
Key.
7. Press the U or D Key to set o.
(The default is o.)
Advanced Function Setting Level
8. Select the Control Output 2 Assignment parameter by pressing the M
Key.
9. Press the U or D Key to set c-o.
(When h-c is selected for the Standard or Heating/Cooling parameter,
the setting will be c-o.)
Advanced Function Setting Level
10. Select the Auxiliary Output 1 Assignment parameter by pressing the M
Key.
11. Press the U or D Key to set alm1.
(The default is alm1.)
Advanced Function Setting Level
12. Select the Auxiliary Output 2 Assignment parameter by pressing the M
Key.
13. Press the U or D Key to set alm2.
(The default is alm2.)
5-hc
h-c
amov
0
Move to Ad-
vanced Function
Setting Level
init
off
Parameter
Initialization
out1
o
Control Output
1 Assignment
out1
o
out2
c-o
Control Output
2 Assignment
out2
c-o
sub1
alm1
Auxiliary Output
1 Assignment
sub1
alm1
sub2
alm2
Auxiliary Output
2 Assignment
sub2
alm2
