129
Appendix
Initial Setting Level
Parameters Charac-
ters
Setting (monitor) Value Display Default Unit Set
Value
Input type in-t Platinum
resis-
tance
thermom-
eter
0: Pt100
1: Pt100
2: Pt100
3: JPt100
4: JPt100
5None
Thermo-
couple
5: K
6: K
7: J
8: J
9: T
22: T
10: E
11: L
12: U
23: U
13: N
14: R
15: S
16: B
Infrared
tempera-
ture sen-
sor
17: 10 to 70°C
18: 60 to 120°C
19: 115 to 165°C
20: 140 to 260°C
Analog
input
21: 0 to 50 mA
Scaling upper limit in-h Scaling lower limit +1 to 9999 100 None
Scaling lower limit in-l −1999 to scaling upper limit −10None
Decimal point dp 0,1 0 None
Temperature unit d-u °C, °F c, f °CNone
Set point upper limit sl-h SP lower limit +1 to input range
lower value (temperature)
1300 EU
SP lower limit +1 to scaling upper
limit (analog)
1300 EU
Set point lower limit sl-l Input range lower limit to SP upper
limit −1 (temperature)
−200 EU
Scaling lower limit to SP upper
limit −1 (analog)
−200 EU
PID ON/OFF cntl ON/OFF, 2-PID onof, pid ON/OFF None
Standard or heating/cooling s-hc Standard or heating/cooling stnd, h-c Standard None
ST st OFF, ON off, on ON None
Control period (OUT1) cp 1 to 99 20 Second
Control period (OUT2) c-cp 1 to 99 20 Second
Direct/reverse operation orev Direct operation, reverse operation or-d, or-r Reverse
operation
None
