Names of Parts Section 1-1
1-1 Names of Parts
1-1-1 Front Panel
E5AZ
E5EZ
1-1-2 Meaning of Indicators
No. 1 display Displays the process value or parameter type.
Lights for approximately one second during startup.
No. 2 display Displays the set point, parameter operation read value, or the variable input
value.
Operation indicators
Temperature unit
No.1 display
No.2 display
Up key
Down keyMode key
Level key
Operation indicators
Operation indicators
Temperature unit
No.1 display
No.2 display
Up key
Down key
Mode key
Level key
