Communications Setting Level Section 5-7
5-7 Communications Setting Level
Each parameter is enabled when the power is reset.
Match the communications specifications of the E5AZ/E5EZ and the host
computer. If a 1 : N connection is being used, ensure that the communica-
tions specifications for all devices in the system (except “Communications
unit No.”) are the same.
Highlighted characters indicate defaults.
Related parameters
“Communications writing” (adjustment level) (page 87)
Communications unit No.
Communications function must be
supported.
Baud rate
Data length
Stop bits
Parity
u-no
bps
len
sbit
prty
Parameter
Displayed
Characters
Set Value Setting Range
Communications
unit No.
u-no 0 to 99
Baud rate bps 1.2/2.4/ 4.8/
9.6/19.2 (kbps)
Data length len 7/8 (bit)
Stop bits sbit 1/2
Parity prty None/even/odd
Function
Setting
0, 1 to 99
1.2 / 2.4 / 4.8 / 9.6 / 19.2 (kbps)
7 / 8 (bit)
1 / 2
none / eVen / odd
See
