123
Appendix
Characteristics
Note The indication of K thermocouples in the −200 to 1300°C range, T and N thermocouples at a tempera-
ture of
−100°C or less, and U and L thermocouples at any temperature is ±2°C±1 digit maximum. The
indication of B thermocouples at a temperature of 400
°C or less is unrestricted.
The indication of R and S thermocouples at a temperature of 200
°C or less is ±3°C±1 digit maximum.
Indication accuracy Thermocouple:
(±0.5% of indication value or ±1°C, whichever is greater) ±1 digit max. (See note.)
Platinum resistance thermometer:
(±0.5% of indication value or ±1°C, whichever is greater) ±1 digit max.
Analog input: ±0.5%FS±1 digit max.
CT input: ±5%FS±1 digit max.
Hysteresis 0.1 to 999.9EU (in units of 0.1EU)
Proportional band (P) 0.1 to 999.9EU (in units of 0.1EU)
Integral time (I) 0 to 3999 (in units of 1 second)
Derivative time (D) 0 to 3999 (in units of 1 second)
Control period 1 to 99 (in units of 1 second)
Manual reset value 0.0 to 100.0% (in units of 0.1%)
Alarm setting range −1999 to 9999 (decimal point position depends on input type)
Sampling period 500 ms
Insulation resistance 20 MΩ min. (at 500 VDC)
Dielectric strength 2000 VAC 50 or 60 Hz 1min
Vibration resistance
10 to 55 Hz, 20 m/s
2
for 10 min. each in X, Y and Z directions
Shock resistance
100 m/s
2
, 3 times each in X, Y, and Z directions
Weight E5AZ Approx. 310 g
E5EZ Approx. 260 g
Adapter: approx. 100 g
Memory protection EEPROM (non-volatile memory) (number of writes: 100,000)
