Using Event Inputs Section 4-5
4-5-5 Executing Run/Stop Control
When “event input assignment 1” or “event input assignment 2” is set to “run/
stop”, control started when event input 1 or 2 becomes “OFF”. Control is
stopped when event input 1 or 2 becomes “ON”. However, alarm output will
be ON according to alarm setting.
While control is stopped, STP (stop) lights.
Note When “number of multi-SP uses” is set to “0” or “1” that is not the
set point setting, run/stop control is possible according to event in-
puts.
Event input assignments 1 and 2 are as follows according to the “number of
multi-SP uses” setting.
• When the number of multi-SP uses is set to either 1 or 2, and event input
assignment 1 or 2 is set to “not displayed,” the setting automatically
becomes “none.”
• When the “number of multi-SP uses” is set to “0”, and both input assign-
ments 1 and 2 can be set, RUN/STOP is assigned to only one event
assignment. The other event assignment is automatically set to OFF.
• When the RUN/STOP function is used for event inputs, RUN/STOP at the
run level is not displayed.
Setting Input Contact State
Event input 1 or 2 ON STOP
Event input 1 or 2 OFF RUN
Number
of
Multi-SP
Uses
Setting Event Input Function
Event input
assignment 1
Event input
assignment 2
Event input 1
function
Event input 2
function
0 NONE STOP NONE RUN/STOP
switching
STOP NONE RUN/STOP
switching
NONE
NONE NONE NONE NONE
1 – (setting data
not displayed)
STOP Multi–SP 2 set
points (set point 0/1
switching)
RUN/STOP
switching
– (setting data
not displayed)
NONE Multi–SP 2 set
points (set point 0/1
switching)
NONE or
RUN/STOP switch-
ing
2 – (setting data
not displayed)
– (setting data
not displayed)
Multi–SP 4 set points
(set point 0/1/2/3 switching)
Symbol Parameters: Level Description
ev-1 Event input 1 assignment:
Advanced function setting level
For event input function
ev-2 Event input 2 assignment:
Advanced function setting level
ev-n Number of multi-SP uses:
Advanced function setting level
Parameters
