Using Heater Burnout Alarm (HBA) Section 3-10
3-10-3 Setup
To activate the heater burnout alarm, set the “HB ON/OFF” parameter
(advanced function setting level) to “ON” and the heater burnout set value in
the “heater burnout detection” parameter (adjustment level).
In this example, let’s set the “heater burnout detection” parameter to “2.5”.
Moving to the advanced function setting level
The default of the “heater burnout” parameter is already “ON”, so set the
“heater burnout detection” parameter.
1,2,3... 1. Move to the advanced function setting level.
Press the key for at least three seconds to move from the “operation
level” to the “initial setting level”.
2. Then move to “advanced function setting level” by pressing the key.
3. Press the key to enter the password (“
−169”), and move from the “ini-
tial setting level” to the “advanced function setting level”.
The top parameter in the “advanced function setting level” is displayed.
4. Select the “HB ON/OFF” parameter by pressing the key.
Make sure that this parameter is set to “ON” (default).
Next, let’s set the “heater current value monitor” parameter.
Operation Procedure
PV/SP
Operation level
HB ON/OFF
Initial setting level
Input type
Move to advanced
function setting
level
Advanced function setting level
amoV
-169
25
100
C
in-t
5
init
off
hbu
on
