Advanced Function Setting Level Section 5-6
• Switches the logic of MB command (communications writing switching) in
the SYSWAY communications procedures.
• The MB command (communications writing switching) is equivalent to the
MB command (remote/local switching) on the E5@J.
• The hatched setting is the default (same logic as E5@J).
(Terms in parentheses () are the terms used on the E5@J.)
■ Related parameters
“Communications writing” (adjustment level) (page 87)
• This parameter is used to set the output delay for Alarm 1, 2, and 3.
• Output’s delayed activation and shutdown can be respectively set.
Alarm type must be set as any type other than 0.
• Related parameters
“Alarm 1, 2, and 3 type” (initial setting level) (page 101 and 102)
MB command logic
switching
Communications function must be
supported.
rlrV
Setting Value
Text Data of MB Command
0000 0001
OFF Communications writing enabled
(remote mode selection)
Communications writing dis-
abled (local mode selection)
ON Communications writing dis-
abled (local mode selection)
Communications writing enabled
(remote mode selection)
Function
Setting
See
Alarm 1 ON delay
Alarm 2 ON delay
Alarm 3 ON delay
Alarm 1 OFF delay
Alarm1, 2, 3 type is not “0: Without
alarm function”
Alarm 2 OFF delay
Alarm 3 OFF delay
a1on
a2on
a3on
a1of
a2of
a3of
Setting Range Units Initial Value
0 to 99 Seconds 0
