102
Initial Setting Level Section 5-5
Select one of the following alarm 2, 3 types:
Deviation/Deviation range/Absolute value
Alarm 2 type
The alarm 2, 3 type must be sup-
ported.
The control must be set to standard
control.
Alarm 3 type
alt3
Set
Value
Alarm Type Alarm Output Operation
When alarm value
X is positive
When alarm value X
is negative
0 Alarm function OFF Output OFF
1 Upper- and lower-limit
(deviation)
(See note 1.)
(See note 2.)
2 Upper-limit (deviation)
3 Lower-limit (deviation)
4 Upper- and lower-limit
range (deviation)
(See note 1.)
(See note 3.)
5 Upper- and lower-limit
alarm with standby
sequence (deviation)
(See note 1.)
(See note 5.)
(See note 4.)
6 Upper-limit alarm with
standby sequence
(deviation)
7 Lower-limit alarm with
standby sequence
(deviation)
8 Absolute-value upper-limit
9 Absolute-value lower-limit
10 Absolute-value upper-limit
with standby sequence
11 Absolute-value lower-limit
with standby sequence
Function
Setting
ON
OFF
LH
SP
X
ON
OFF
SP
ON
OFF
SP
X
X
ON
OFF
SP
ON
OFF
SP
X
ON
OFF
SP
LH
ON
OFF
SP
LH
ON
OFF
SP
X
ON
OFF
SP
X
ON
OFF
SP
X
ON
OFF
SP
X
ON
OFF
0
X
ON
OFF
0
X
ON
OFF
0
X
ON
OFF
0
X
ON
OFF
0
X
ON
OFF
0
X
ON
OFF
0
X
ON
OFF
0
X
