131
Appendix
Advanced function setting level
Parameters Charac-
ters
Setting (monitor) Value Display Default Unit Set
Value
Parameter initialization init OFF, ON off, on OFF None
Number of multi-SP uses ev-m 0 to 2 1 None
Event input assignment 1 ev-1 None, run/stop none, stop None None
Event input assignment 2 ev-2 None, run/stop none, stop RUN/STOP None
Multi-SP uses mspu OFF, ON off, on OFF None
SP ramp monitor sprt OFF, 1 to 9999 off, 1 to 9999 OFF EU
Standby sequence reset rest Condition A, Condition B a, b Condition A None
Alarm 1 open in alarm al1n Open in alarm/Close in alarm n-o, n-c Close in
alarm
None
Alarm 1 hysteresis alh1 0.1 to 999.9 0.2 EU
Alarm 2 open in alarm al2n Open in alarm/Close in alarm n-o, n-c Close in
alarm
None
Alarm 2 hysteresis alh2 0.1 to 999.9 0.2 EU
Alarm 3 open in alarm al3n Open in alarm/Close in alarm n-o, n-c Close in
alarm
None
Alarm 3 hysteresis alh3 0.1 to 999.9 0.2 EU
HB ON/OFF hbu OFF, ON off, on ON None
Heater burnout latch hbl OFF, ON off, on OFF None
Heater burnout hysteresis hbh 0.1 to 50.0 0.1 A
ST stable range st-b 0.1 to 999.9 15.0 EU
Alpha alfa 0.00 to 1.00 0.65 None
MV upper limit ol-h MV lower limit +0.1 to 105.0
(standard)
105.0 %
0.0 to 105.0 (heating/cooling) 105.0 %
MV lower limit ol-l −5.0 to MV upper limit −0.1
(standard)
−5.0 %
−105.0 to 0.0 (heating/cooling) −105.0 %
Input digital filter inf 0.0 to 999.9 0.0 Second
Additional PV display pvad OFF, ON off, on OFF None
MV display o-dp OFF, ON off, on OFF None
Automatic display return
time
ret OFF, 1 to 99 off, 1 to 99 OFF Second
Alarm 1 latch a1lt OFF, ON off, on OFF None
Alarm 2 latch a2lt OFF, ON off, on OFF None
Alarm 3 latch a3lt OFF, ON off, on OFF None
Move to protect level time prlt 1 to 30 3 Second
Input error output sero OFF, ON off, on OFF None
Cold junction compensa-
tion method
cjc OFF, ON off, on ON None
MB command logic
switching
rlrv OFF, ON off, on OFF None
Alarm 1 ON delay a1on 0 to 99 0 Second
Alarm 2 ON delay a2on 0 to 99 0 Second
Alarm 3 ON delay a3on 0 to 99 0 Second
Alarm 1 OFF delay a1of 0 to 99 0 Second
Alarm 2 OFF delay a2of 0 to 99 0 Second
Alarm 3 OFF delay a3of 0 to 99 0 Second
