9
Communications Function Section 1-4
3. Pressing the key advances the parameters as shown in the following
figure.
4. Press the or key to change the parameter setups.
Setting up
communications data
Set the E5AZ/E5EZ communications specifications so that they match the
communications setup of the host computer.
Communications unit No.
Baud rate
Data length
Stop bits
Parity
Parameter Displayed
Characters
Set (monitor) Value Settings Default Unit
Communications unit No. u-no 0 to 99 1 None
Baud rate bps 1.2, 2.4, 4.8, 9.6, 19.2 1.
2, 2. 4, 4. 8, 9. 6,
19.
2
9.6 kbps
Data length len 7, 8 7 bit
Stop bits sbit 1, 2 2 bit
Parity prty None, even, odd none, even, odd Even None
