Omron E5AZ - Page 79

60
Setting Scaling Upper and Lower Limits (for Analog Inputs) Section 4-3
In this example, let’s set the scaling upper- and lower-limits to display 0 to
50 mV as 10.0% to 95.0%.
1,2,3... 1. Press the key for at least three seconds to move from the “operation
level” to the “initial setting level”.
2. Select “scaling upper limit” by pressing .
3. Press the or key to set the parameter to “950”.
4. Select “scaling lower limit” by pressing .
5. Press the or key to set the parameter to “100”.
6. Select the decimal point position by pressing .
7. Press the or key to set the parameter to “1”.
8. To return to the “operation level” press the key for at least one second.
Operation Procedure
Input type
Initial setting level
Scaling upper
limit
Scaling lower
limit
Decimal point
in-t
21
in-h
100
in-h
950
in-l
0
in-l
100
dp
0
dp
1
