5
Item Specification
Indication method E5AJ All digital indication (PV: Red, 15 mm; SV: Green,
10.5 mm)
E5EJ All digital indication (PV: Red, 14 mm; SV: Green,
9.5 mm)
E5CJ All digital indication (PV: Red, 12 mm, SV: Green 8.0
mm)
Event input Contact input: ON: 1 kΩ max. OFF: 100 kΩ min.
No-contact input: ON: residual voltage of 3 V max; OFF:
current leakage of 1 mA max.
Other function • Key protect
• Cooling operation/Heating operation
• Heater burnout alarm
Model with event input (E5J-B)
• Set point selection (set point x 2)
• RUN/STOP (E5AJ-B and E5EJ-B only)
Ambient operating temperature –10°C to 55°C (with no condensation)
Ambient operating humidity 35 to 85%
Storage temperature –25°C to 65°C (with no condensation)
Model Specification
E53-R Relay Output Unit SPDT (SPST-NO when used with the
E5J), 5 A at 250 VAC (resistive load)
E53-Q Voltage Output Unit NPN, 40 mA at 12 VDC (with
short-circuit protection)
E53-Q3 Voltage Output Unit NPN, 20 mA at 24 VDC (with
short-circuit protection)
E53-Q4 Voltage Output Unit PNP, 20 mA at 24 VDC (with
short-circuit protection)
E53-C3 Linear Output Unit 4 to 20 mA DC with a load of 600 Ω
max. (with a resolution of approximately
2600 when used with the E5J) (see
note)
E53-C3D Linear Output Unit 0 to 20 mA DC with a load of 600 Ω
max. (with a resolution of approximately
2600 when used with the E5J)
E53-V34 Linear Output Unit 0 to 10 VDC with a load of 1 kΩ min.
(with a resolution of approximately 2600
when used with the E5J)
E53-V35 Linear Output Unit 0 to 5 VDC with a load of 1 kΩ min.
(with a resolution of approximately 2600
when used with the E5J)
Note The E53-C cannot be used.
Item Specification
Maximum continuous heater current 50 A
Dielectric strength 1,000 VAC
Vibration resistance 50 Hz, approx. 98 m/s
2
(10G)
Weight E54-CT1: Approx. 11.5 g
E54-CT3: Approx. 50 g
Output Units
Current Transformer (CT)
Specifications
Section 1-3
To Next Page
