6
1-3-2 Characteristics
E5J
Item Specification
Indication accuracy ±0.5% or ±1°C whichever is larger ± 1 digit max.
Thermocouple K, T, or N at a temperature of –100°C; thermocouple U at ± 2°C ± 1
digit max.
Hysteresis (for ON/OFF control) 0.1 to 999.9°C/° F (in units of 0.1°C/°F)
Proportional band 0.1 to 999.9°C/°F (in units of 0.1°C/°F)
Integral time 0 to 3999 s (in units of 1 s)
Derivative time 0 to 3999 s (in units of 1 s)
Control period Relay or voltage output:1 to 99 s (in units of 1 s)
Manual reset value (I = 0) 0.0 to 100.0% (in units of 0.1%)
Alarm setting range With K, J, L, or N input: –1999 to 9999° C/°F (in units of 1°C/°F)
With JPt100, Pt100, T, or U input: –199.9 to 999.9° C/°F (in units of 0.1°C/°F)
Sampling period 500 ms
Output refresh period 500 ms
Display refresh period 500 ms
Insulation resistance 20 MΩ min. at 500 VDC (measured with an Output Unit)
Dielectric strength 2000 VAC, 50/60 Hz for 1 min. between charged terminals different from each other
in polarity
Vibration
Malfunction 10 to 55 Hz, 9.8 m/s
2
(1G) 10 min. in X, Y, and Z directions
resistance
Destruction 10 to 55 Hz, 19.6 m/s
2
(2G) 2 hr. in X, Y, and Z directions
Shock resistance Malfunction 196 m/s
2
(20G) 3 times each in 3-axis 6 directions (98 m/s
2
(10G) for the relay)
Destruction 294 m/s
2
(30G) 3 times each in 3-axis 6 directions
Weight E5AJ Approx. 360 g; mounting bracket: approx. 65 g
E5EJ Approx. 280 g; mounting bracket: approx. 65 g
E5CJ Approx. 170 g; adapter: approx. 10 g
Enclosure rating Front panel: E5AJ/E5EJ: IEC standard IP54
E5CJ: IEC standard IP50 (see note 1)
Rear case: IEC standard IP20
Terminals: IEC standard IP00
Memory Protection Non-volatile memory
EMC Emission Enclosure: EN55011 Group 1 class A
Emission AC Mains: EN55011 Group 1 class A
Immunity ESD: EN61000-4-2: 4 kV contact discharge (level 2)
8 kV air discharge (level 3)
Immunity RF-interference: ENV50140: 10 V/m (amplitude modulated,
80 MHz to 1 GHz) (level 3)
10 V/m (pulse modulated,
900 MHz)
Immunity Conducted Disturbance: ENV50141: 10 V (0.15 to 80 MHz) (level 3)
Immunity Burst: EN61000-4-4: 2 kV power-line (level 3)
2 kV I/O signal-line (level 4)
Approved standards UL1092, CSA C22.2 No. 142
Conforms to EN50081-2, EN50082-2, EN61010-1 (IEC1010-1) (see note 2)
Conforms to VDE0106/part 100 (Finger Protection), when the separately-ordered
terminal cover is mounted.
Note 1. The model numbers of the exclusive watertight covers conforming to IP66,
NEMA4 are as follows:
For E5AJ: Y92A-96N; For E5CJ: Y92A-48N; For E5EJ: Y92A-49N
2. Basic insulation is between the input and output.
Specifications
Section 1-3
