Omron E5CJ-R2 User Manual

Appendix ADimensions/Mounting Holes
67
Mounting Holes
45
45
60 min.
(48 x units – 2.5)
+1
0
+0.6
0
+0.6
0
45
+0.6
0
Note 1. All dimensions shown are in millimeters.
2. Side-by-side close mounting is not possible for E5CJs equipped with the Watertight Cover (sold sepa-
rately).
Terminal Covers
E53-COV02 E5AJ with Terminal Cover
112
12 115
E53-COV04 E5CJ with Terminal Cover
115
9.5
58
