F3SJ-B
User’s Manual
Introduction
E
Contents
Legislation and Standards i
Terms and Conditions Agreement ii
Precautions on Safety iv
Precautions for Safe Use viii
Precautions for Correct Use viii
Chapter1 Overview and Specifications 1
Basic Configuration and Names 2
Model Overview 3
Internal (LED) Indicator Display Pattern 4
Ratings/Specifications 6
Model/Current Consumption List 8
Chapter2 System Configuration and Functions 9
Wiring Diagrams 10
Minimum wiring required to check the operation of the F3SJ-B 10
Wiring in use 11
Description of Functions 12
External Test Function 12
Self-test Function 13
Lockout Reset Function 14
Auxiliary Output Function 15
Chapter3 Wiring/Installation 17
Installation Conditions 18
Detection Zone and Approach 18
Safety Distance 19
Distance from Reflective Surfaces 23
Mutual Interference Prevention 23
Series Connection 25
Connection Procedure 27
Dimensions 28
When Using Top/Bottom and Intermediate Brackets 29
When Using Intermediate Brackets Only (Free-Location Mounting) 33
When Using One-touch Brackets 37
When Using Replacement Brackets 42
When Using Contact Mount Brackets 45
When Using Spatter Protection Cover 48
