Chapter3 Mounting
Wiring/Installation
E
Mounting

Mounting Method
Mounting methods include use of Top/Bottom Brackets, Top/Bottom Brackets + Intermediate Brackets,
Intermediate Brackets only (Free-Location Mounting) and use of One-touch Brackets. Any of these
mounting methods allows the user to use the same bracket for the backside mounting and side
mounting.
 Number of Brackets Required
The numbers of brackets required according to the protective heights of the sensor are as follows:
•When Using Top/Bottom Brackets Only --> p.50
•When Using Top/Bottom + Intermediate Brackets --> p.52
• When Using Intermediate Brackets Only --> p.56
• When Using One-touch Bracket --> p.59
Protective height
Number of Top/
Bottom Brackets
Number of
Intermediate Brackets
0185 to 1105 2 0
1185 to 1345 2 1
1425 to 2065 2 2
Protective height
Number of
Intermediate Brackets
0185 to 0225 1
0305 to 1105 2
1185 to 1585 3
1665 to 2065 4
Protective height
Number of One-touch
Brackets
0185 to 1105 2
1185 to 1585 3
1665 to 2065 4
