Omron F3SJ-B Series - When Using Contact Mount Brackets

45
F3SJ-B
User’s Manual
Chapter3 Dimensions
Wiring/Installation
E
 When Using Contact Mount Brackets
 Backside mounting
- The protective height of the F3SJ-E/B series that supports the contact mount bracket is limited.
Protective height allowed for mounting: 185 mm to 1,105 mm.
- Brackets of other models such as F39-LJB1 cannot be used simultaneously.
30
30
32
2
2
Contact Mount
Bracket
(F39-LJB5)
Contact Mount
Bracket
(F39-LJB5)
B
D
22.5
10.75
3.25
7
A
6.5
30
34.5
Dia. 9
19
30
P(beam gap)
C(Protective height)
C
B
3.25
2-M8
3.25
C
B
19
<M5 screw fixed> <M8 screw fixed>
4-M5
M3 x 6 screw
M3 x 6 screw
Dimensions A to D
AC+69
B C+47.5
C 4-digit number in the Model name (protective height)
DC-45
