Omron F3SJ-B Series - Lockout Reset Function

14
Chapter2 Description of Functions
F3SJ-B
User’s Manual
System Configuration and Functions
 Lockout Reset Function
When the cause of the lockout is removed, you can release the lockout by using either of the following
methods.
•Cycle the power back ON
•Reset input
Open or apply 1/2 Vs to Vs to the reset input line (yellow) for 1 s or longer, and then apply a voltage of
0 V to 3 V again.
