43
F3SJ-B
User’s Manual
Chapter3 Dimensions
Wiring/Installation
E
 Side mounting
Bracket mounting procedure (Mounting) p.49
If the protective height is more than 1105 mm, use Intermediate Brackets of the quantities and locations according to
the dimensions described on page 29 "When Using Top/Bottom and Intermediate Brackets". If the brackets described
above are not used, ratings and performance cannot be met.
[ Unit : mm ]
36.5
79.5
A
C (Protective height)
B
46
2
30
30
19
6.5
30
62
19
B
4-M5
Replacement Bracket
(F39-LJB4)
Replacement Bracket
(F39-LJB4)
M3 x 6 screw
M3 x 6 screw
Dimensions A to E and P
A C+159
BC+86
C 4-digit number of the type name (protective height)
