Omron fh series Hardware Setup Manual

Appear-
ance
Description Model
Cable with Rugged type Connectors on Both Ends (M12 L/RJ45)
• Wire Gauge and Number of Pairs:
A
WG22, 2-pair Cable
• Cables length:
0.3 m, 0.5 m, 1 m, 2 m, 3 m, 5 m, 10 m, 15 m
XS5W-T422-
£MC-K
-
For Ether-
CAT and
EtherNet/I
P
Wire
Gauge and
Number of
Pairs:
AWG24, 4-
pair Cable
Cables Hitachi Metals, Ltd. NETSTAR-C5E
SAB 0.5 x 4P CP
*2
-
Kuramo Electric Co.
KETH-SB
*2
-
SWCC Showa Cable Systems Co.
FAE-5004
*2
-
JMACS Japan Co.,Ltd.
IETP-SB
*2
-
RJ45 Con-
nectors
Panduit Corporation
MPS588-C
*2
-
Wire
Gauge and
Number of
Pairs:
A
WG22, 2-
pair Cable
Cables Kuramo Electric Co. KETH-PSB-OMR
*3
-
JMACS Japan Co.,Ltd.
PNET/B
*3
-
SWCC Showa Cable Systems Co.
FAE-5002
*3
RJ45 As-
sembly
Connector
OMRON XS6G-T421-1
-
For Ether-
Net/IP
Wire
Gauge and
Number of
Pairs:
0.5mm x
4P
Cables Fujikura Ltd. F-LINK-E 0.5mm
x 4P
*4
-
RJ45 Con-
nectors
Panduit Corporation
MPS588
*4
*1. The lineup features Low Smoke Zero Halogen cables for in-cabinet use and PUR cables for out-of-cabinet
use.
*2. We recommend you to use above cable for EtherCAT and EtherNet/IP, and RJ45 Connector together.
*3. We recommend you to use above cable for EtherCAT and EtherNet/IP, and RJ45 Assembly Connector to-
gether
.
*4. We recommend you to use above cable for EtherNet/IP and RJ45 Connectors together.
Precautions for Correct Use
Please be careful while cable processing, for EtherCAT, connectors on both ends should be
shield connected and for EtherNet/IP
, connectors on only one end should be shield connected.
1 Confirm the Package
1-10
FH Series Vision System Hardware Setup Manual for 3D Robot Vision (Z436-E1)
