also required when mounting multiple Sensor Controllers side by side. For the back mount-
ing, the back-side clearance of 15 [mm] is not required.
Handling a SD memory card
•
Before removing a SD memory card, make sure that data is not being read or written to them.
• For SD memory card, the SD BUSY LED flashes or lights while data is being read or written,
so make sure that it is turned OFF before removing the memory.
• Do not insert an SD memory card in the reverse orientation, at an angle, or in a twisting man-
ner.
4 Handling and Installation Environment
4-4
FH Series Vision System Hardware Setup Manual for 3D Robot Vision (Z436-E1)

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
