Inspecting with the Sensitive Search Inspection Item
160
FQ2-S4 User’s Manual
Measurement Data That Can Be Used for External Outputs and Calculations
The following values can be used as measurement data and output to external devices via the Ethernet or used
in calculations.
4-17 Calculations and Judgements Using Inspection Item Data: p. 197
Expression text string Data name Description Data range
JG Judgement This is the judgement result of the
sensitive search.
−2: No judgement (not measured),
0: Judgement is OK,
−1: Judgement is NG,
−13: Teaching not performed error,
−14: Figure not registered error,
−15: Out of range error
CR Correlation Correlation 0 to 100
DV Deviation Density deviation 0 to 221
X Position X This is the X coordinate of the position
where the model was found.
−999,999,999.9999 to
999,999,999.9999
Y Position Y This is the Y coordinate of the position
where the model was found.
−999,999,999.9999 to
999,999,999.9999
TH Angle This is the angle of the position where
the model was found.
−180 to 180
RX Detection X This is the X coordinate of the detec-
tion point when the model was regis-
tered.
−999,999,999.9999 to
999,999,999.9999
RY Detection Y This is the Y coordinate of the detec-
tion point when the model was regis-
tered.
−999,999,999.9999 to
999,999,999.9999
SX Reference position X This is the X coordinate of the position
where the model was registered.
(This is the center of the model
region.)
−999,999,999.9999 to
999,999,999.9999
SY Reference position Y This is the Y coordinate of the position
where the model was registered.
(This is the center of the model
region.)
−999,999,999.9999 to
999,999,999.9999
ST Reference angle This is the angle when the model was
registered.
−180 to 180
CT NG sub-region This is the number of NG sub-regions. 0 to 100
AN Sub-region number This is the number of the regions with
the lowest correlation.
0 to 99
ANX Sub-region number (X) This is the column number in the X
direction of the output region.
0
ANY Sub-region number (Y) This is the row number in the Y direc-
tion of the output region.
0
DX Sub-region pos. X This is the X coordinate of the sub-
region that was found.
−999,999,999.9999 to
999,999,999.9999
DY Sub-region pos. Y This is the Y coordinate of the sub-
region that was found.
−999,999,999.9999 to
999,999,999.9999
CRN[0] to CRN[99] Correlation (sub-region) This is the correlation of the sub-
region that was found.
0 to 100
DVN[0] to DVN[99] Deviation (sub-region) This is the density deviation of the
region that was found.
0 to 221
To Next Page
