Outputting Data and Controlling Operation through EtherNet/IP
346
FQ2-S4 User’s Manual
Setting the Output Format
[In/Out] − [I/O setting] − [Output data setting] − [Link data output]
1 Press [Output format].
2 Press [Output form].
3 Set either a floating point decimal or a fixed decimal for the output form.
Outputting Character Strings
You can set whether to output the character string that results from reading. Outputting the character string is
possible for the following inspection results.
•OCR
• Bar code
• 2D-code
• 2D-code (DPM)
The procedure for outputting the character string is given here for two inspection items.
[In/Out] − [I/O setting] − [Output data set] − [Link data output] − [Output data set]
1 Select the inspection item for which to output the character string.
2 Set the following items on the setting display.
Item Description Setting range
Output form
Set the output form for numerical data. Floating point or fixed point (default: Floating
point)
Parameter Setting Description
String output ON/OFF OFF (default)
Ye s
Sets whether to output the character string that results
from reading.
Partial output ON/OFF No (default)
Ye s
Sets whether to specify the range of characters to output.
Output string setup 1 to 128 for OCR
1 to 1024 for Bar code, 2D-
code, or 2D-code (DPM)
Sets the output range.
NG String output on/off Yes (default)
No
Sets whether to output an NG string.
▲ ▲
To Next Page
