External Reference Parameters
FQ2-S4 User’s Manual
531
Appendices
12
300 Logging
condi-
tions
Number of data log
records
Setting/Acqui-
sition
1 to 32 32 --- ---
310 Data logging switch for
entire unit
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
311 Data logging switch for
judgement
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
312 Data logging switch for
correlation
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
313 Data logging switch for
position X
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
314 Data logging switch for
position Y
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
315 Data logging switch for
measurement angle
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
321 Data logging switch for
detection count
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
700 Display
settings
Correlation display Setting/Acqui-
sition
0: Display, 1: Do not display 0 --- ---
701 Position X display Setting/Acqui-
sition
0: Display, 1: Do not display 0 --- ---
702 Position Y display Setting/Acqui-
sition
0: Display, 1: Do not display 0 --- ---
703 Measurement angle
display
Setting/Acqui-
sition
0: Display, 1: Do not display 0 --- ---
704 Count display Setting/Acqui-
sition
0: Display, 1: Do not display 0 --- ---
800 Position X display pat-
tern
Setting/Acqui-
sition
0: Absolute value, 1: Rela-
tive value
0 --- ---
801 Position Y display pat-
tern
Setting/Acqui-
sition
0: Absolute value, 1: Rela-
tive value
0 --- ---
802 Measured angle display
pattern
Setting/Acqui-
sition
0: Absolute value, 1: Rela-
tive value
0 --- ---
External
refer-
ence
number
Category Data name Setting/Acqui-
sition
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
