Inspection Item Selection Guide
FQ2-S4 User’s Manual
4
Setting Up Inspections
91
Dividing the measurement area and judging
according to shapes for each division
Judging minute differences in printed
labels
Sensitive
Search
p. 155
Judging according to positions Measuring the position offset of a
seal
Edge Posi-
tion
p. 162
Judging according to widths Measuring the width between lead
wires
Edge
Width
p. 169
Judging according to the features of parts of a
shape
Judging the number of pins Edge Pitch p. 147
Judging according to colors Detecting parts Color Data p. 178
Judging according to sizes Judging if there is silver paste Area p. 182
Inspection Example Inspection
items used
Refer-
ence
LED RADIATION
DO NOT STARE
INTO BEAM
CLASS 2 LED PRODUCT
JIS C 6802:2005
Max.65mW
400-700nm
LED RADIATION
DO NOT STARE
INTO BEAM
CLASS 2 LED PRODUCT
JIS C 6802:2005
Max.65mW
400-700nm
OK
NG
OK NG
OK NG
OK
NG
NG
OK NG
OK NG
