29
Select the image.
button
Specifies the image file to re-inspect.
The judgment result
monitor. check box
If this check box is selected, the judgment results are monitored
during continuous measurements.
The judgment result
monitor condition
button
Drop-down list to select the condition to monitor the judgment re-
sults.
Image counter Displays the current count of images and the total number of images
in the folder in which the specified image is located (*).
Images in the folder are sorted in ascending order by the file names,
and numbered in the order starting from the first image with 1.
* Only images in the directly specified folder are counted. Those in subfolders are not count-
ed.
Caution
Simulator menu pane is enabled only on Setup Mode. It is disabled on Run Mode.
The Load from file button and Save to file button are only valid for data about the sensor.
The setting data of TouchFinder is not supported.
During a continuous measurement, the only available button is the Continuous meas. but-
ton. Other buttons are unavailable including those on TouchFinder display.
4.3. Loading Measurement Images
This section describes the procedure to specify images to inspect on FQ2 Simulator.
If you want to inspect images taken by a digital camera or image data saved by FQ2 Smart
Camera series, save them in a folder on your computer. Here is a recommended procedure.
Caution
When setting/adjusting inspection items on FQ2 Simulator, use image logs created on the
actual FQ2 sensor to be used. Settings/adjustments may not be optimized if image logs from
other sensor with different color settings or resolution are used.
Differences of the color setting may cause an error for unregistered model, and the difference
of the resolution may cause different setting range of inspection items from the FQ2 sensor.
1. When you install FQ2 Simulator, the OMRON FQ folder is automatically created in Docu-
ments. Save images for inspection in the SDCard folder in the OMRON FQ folder. You can
create a subfolder in the SDCard folder, if you want.
C:\Users\User name\Documents\OMRON FQ\SDCard
To Next Page
