51
4.8. How to Exit FQ2 Simulator
This section describes how to exit FQ2 Simulator.
1. Stop inspection.
2. Click File on Menu bar.
3. Click End.
4. The End dialog box appears.
Elements Description
End button You will automatically exit FQ2 Simulator.
Data save and exit
button
The whole setting data made on FQ2 Simulator (*1) are saved and
FQ2 Simulator is closed.
The setting data will be saved in the following destination.
C:\Users\User name\Documents\OMRON
FQ\SDCard\SettingData\FQ2-S_Sim*** *
2
.
Cancel button
The End dialog box will close without exiting FQ2 Simulator.
*1 The whole setting data here includes the scene group data, sensor system data, calibration
group, and dictionary data.
*2 xxx as in FQ2-S_Simxxx is the version number of FQ2 Simulator.
5. Click End or Data save and exit.
