102
Follow the steps below to change the H setting value from 600 to 700 while the
process value is displayed in RUN mode, provided that the HH setting value is
already displayed on the SV display.
1, 2, 3... 1. Press the Mode Key to display the H setting value and to light the H indicator
of the SV display status indicators.
2. Press the Shift Key to display all the digits of the setting value 600 for chang-
ing.
3. Press the Up and Shift Keys to set the value to 00700.
4. The input will be entered if nothing else is input within five seconds.
or Press the Mode Key to display the L setting value for changing. The H set-
ting value will appear again if nothing else is input within five seconds.
SETTING
EXAMPLE
Set Value LED Display
Model
Displaying and Changing Setting Values
Section 5-1
