4-1 Overview
4-1-1 Heading Symbols
The following symbols are used for headings in this section.
This symbol precedes an explanation of the parameter’s meaning and function.
This symbol precedes a description of the settings, setting range, and default
value.
This symbol precedes an explanation of procedures for parameters that specify
operations.
This symbol precedes a listing of references and related parameters.
This symbol precedes a listing of the models in which this parameter can be
used.
4-1-2 Setting Procedures
• The K3NR has four modes: RUN mode for normal operations, Setting mode
for initial parameter input, Protect mode for lock-out configuration, and Mainte-
nance mode for initializing set values. The parameters that are accessible on
any individual K3NR will vary depending on the Output Board installed. Refer
to Appendix D Available Parameters.
• The K3NR is in RUN mode when the K3NR is turned on. Parameter settings in
protect or setting mode are described below on the basis that the parameters
are set for the first time.
For the operation in RUN mode, refer to Section 5 Operations in RUN Mode.
• The setting examples are provided on condition that the factory-set values of
the K3NR have not been changed.
FUNCTION
SETTING
PROCEDURE
REFERENCE
MODELS
Overview Section 4-1
