Appendix E
Available Parameters
Available parameters vary with the output board of the K3NR and are indicated as “YES” in the following table.
K3NR-jBjA Basic Model
Menu Parameter
Output board
No
output
C1/C2/
C5/T1/T2
(note 2)
B2 B4 L1/L2/
L3/L7/
L8
L4/L5/
L6/L9/
L10
FLK1/
FLK2/
FLK3
FLK4/
FLK5/
FLK6
sUset
Si
s.bank Bank no. of set value
YES YES YES YES
Setting
value
sU*.hh HH set value
YES YES YES YES
va
l
ue
menu
sU*. h H set value
YES YES YES YES
menu
sU*. l L set value
YES YES YES YES
sU*.ll LL set value
YES YES YES YES
pscl
Pl
p.bank Bank no. of prescale
YES YES YES YES YES YES YES YES
Prescal-
ing menu
ps*.ax Prescaling value
X (mantissa) of input A
YES YES YES YES YES YES YES YES
ps*.ay Prescaling value
Y (exponent) of input A
YES YES YES YES YES YES YES YES
ps*.bx Prescaling value
X (mantissa) of input B
YES YES YES YES YES YES YES YES
ps*.by Prescaling value
Y (exponent) of input B
YES YES YES YES YES YES YES YES
decp.* Decimal point position
YES YES YES YES YES YES YES YES
setup
S
func Operating mode
YES YES YES YES YES YES YES YES
Setup
menu
ina/inb Sensor type
YES YES YES YES YES YES YES YES
menu
=ro.ax Auto zero time
X (mantissa) of input A
YES YES YES YES YES YES YES YES
=ro.ay Auto zero time
Y (exponent) of input A
YES YES YES YES YES YES YES YES
=ro.bx Auto zero time
X (mantissa) of input B
YES YES YES YES YES YES YES YES
=ro.by Auto zero time
Y (exponent) of input B
YES YES YES YES YES YES YES YES
time Time unit
YES YES YES YES YES YES YES YES
uĆno Communications unit no.
YES YES
bps Baud rate
YES YES
len Word length
YES YES
sbit Stop bits
YES YES
prty Parity bits
YES YES
opt
Option
menu
aUg Process time for
averaging measured
value
YES YES YES YES YES YES YES YES
stine Startup compensation
time
YES YES YES YES YES YES YES YES
memo Power failure memory
YES YES YES YES YES YES YES YES
hys Hysteresis
YES YES YES YES
cĆout Output pattern
YES YES YES YES
lset.h H linear output range
YES
(note 1)
YES
(note 1)
lset.l L linear output range
YES
(note 1)
YES
(note 1)
rĆl Remote/Local
programming
YES YES
