Omron K3NR User Manual

Appendix EAvailable Parameters
136
Menu Output boardParameterMenu
FLK4/
FLK5/
FLK6
FLK1/
FLK2/
FLK3
L4/L5/
L6/L9/
L10
L1/L2/
L3/L7/
L8
B4B2C1/C2/
C5/T1/T2
(note 2)
No
output
Parameter
prot
P
all All key protect
YES YES YES YES YES YES YES
Protect
menu
sUset Set value change
prohibit
YES YES YES YES
reset Counting value reset
prohibit
YES YES YES YES YES YES YES YES
mm.rst Maximum/Minimum
value clear prohibit
YES YES YES YES YES YES YES YES
secr Security
YES YES YES YES YES YES YES YES
Note 1. The linear output range cannot be set with the K31-L3 and K31-L6 Output Boards.
2. The HH and LL set values cannot be set with the K31-C1.
3. The selected bank number will be displayed where an asterisk (*) appears.
K3NR-jBjC Set Value LED Display Model
Menu Parameter
Output board
C1/C2/C5/
T1/T2
(note 2)
B4 L4/L5/
L6/L9/
L10
FLK4/
FLK5/
FLK6
sUset
Si l
s.bank Bank no. of set value
YES YES YES YES
Setting value menu
sU.hh HH set value
YES YES YES YES
sU. h H set value
YES YES YES YES
sU. l L set value
YES YES YES YES
sU.ll LL set value
YES YES YES YES
pscl
Pli
p.bank Bank no. of prescale
YES YES YES YES
Prescaling menu
ps*.ax Prescaling value X (mantissa) of input A
YES YES YES YES
ps*.ay Prescaling value Y (exponent) of input A
YES YES YES YES
ps*.bx Prescaling value X (mantissa) of input B
YES YES YES YES
ps*.by Prescaling value Y (exponent) of input B
YES YES YES YES
decp.* Decimal point position
YES YES YES YES
setup
S
func Operating mode
YES YES YES YES
Setup menu
ina/inb Sensor type
YES YES YES YES
=ro.ax Auto zero time X (mantissa) of input A
YES YES YES YES
=ro.ay Auto zero time Y (exponent) of input A
YES YES YES YES
=ro.bx Auto zero time X (mantissa) of input B
YES YES YES YES
=ro.by Auto zero time Y (exponent) of input B
YES YES YES YES
time Time unit
YES YES YES YES
uĆno Communications unit no.
YES
bps Baud rate
YES
len Word length
YES
sbit Stop bits
YES
prty Parity bits
YES
