4-2-3 Setting Value Menu (sUset)
Bank No. of Set Value
HH Set Value
H Set Value
L Set Value
LL Set Value
• There are two basic methods for setting HH, H, L, and LL set values: by enter-
ing during RUN mode via the front-panel buttons, setting in Setting mode, or by
the teaching function.
Setting Setting range Default
Set value bank 1 to 4 1
HH set value
–19,999 to 99999
99,999
H set value
,
99,999
L set value –19999
LL set value –19999
Set the decimal point position in the prescaling menu.
Refer to 6-1 Teaching Function.
• The menu is only available for the K3NR with Comparative Output Board.
s.bank
sU*.hh
sU*.h
sU*.l
sU*.ll
