6
Used to select a parameter to be displayed for setting value change.
Used to increment the current digit in the setting value by one.
The value increases in the following order:
0, 1, 2, 3, 4, 5, 6, 7, 8, 9, (–1), and (–)
Only the leftmost digit will be displayed if the value is set to “–1” or“ –.”
The value will be set to 0 if this key is pressed when “9” or “–” is displayed.
Used to change the parameter displayed in setting mode.
Used to scroll the digit to the right of the presently displayed digit.
Used to reset the maximum value, minimum value, or counting value in RUN
mode.
Used to select the teaching function. Refer to 6-1 Teaching Function for details.
Up Key
Shift Key
RESET/TEACH Key
Front of the Meter
Section 1-2
