Chapter 3: Setup
A
Figure 3-23. Thru-hole for Brake-release Cable, (A) 6 mm diameter (0.25 in.) pass-through hole for
brake cable, through rear frame tube
A
B
C
Figure 3-24. Thru-holes for Brake-release Cable, Plate Removed
