Omron NJ Series Startup Guide

5 Repeat step 4 above.
A new row with the Collision Filter Group Name set as Group1 is added on the Scene
Graph dialog box.
6 Click the ... button in the Collision Filter Group Items column for Group0 - [0].
The Select a collision filter group item dialog box is displayed.
3 Implementation Example of Static Pick-and-place Equipment
3-51
NJ-series Robot Integrated System Startup Guide (O049)
3-3 Programming and Simulation Procedures
3
3-3-5 Placing 3D Shape Data

Omron NJ Series Specifications

General

Program Capacity	Up to 128 MB
SD Card Slot	Yes
Power Supply Voltage	24 VDC
Motion Control	Yes
USB Ports	1
Operating Temperature	0°C to 55°C
Communication Interfaces	Ethernet/IP, EtherCAT, USB
Safety Function	Optional
Storage Temperature	-20°C to 75°C
Communication Ports	USB
Dimensions	Varies by model
Weight	Varies by model
