3-2 Quick Reference
49
3-2 Quick Reference
The following table provides a quick reference to Ladder Monitor functions and manual
pages that provide details.
Item Procedure See
Search To jump from a user
screen to the location
where an alarm occurred.
1. Select the alarm to search for from the
Alarm/Event Summary and History.
2. Start the Ladder Monitor.
Page 58
To search for a specified
address.
1.
Search
Button -
Address
2. Input the address to be found.
3. Select the search task.
4. Press the
Search
Button.
Page 52
To search for the address
currently indicated by the
cursor.
Press the
Next
Button.
When the address is found, the cursor will
be displayed at that location. Press the
Next
Button again to continue searching
for the same address.
Page 55
To jump from an input bit
to the sequence output
instruction for the same
address.
Press the input bit twice consecutively in
the ladder display area.
Page 56
To jump from a sequence
output instruction to the
input bit for the same
address.
Press the output twice consecutively in the
ladder display area.
Page 57
To return to a program
section that was
previously found.
Press the
Back
Button.
Page 57
If you already know the
step number (program
address).
1.
Search
Button –
Jump
2. Specify the task and input the task
number and step number (program
address).
3. Press the
Search
Button.
Page 52
To search for a specified
address in an output
instruction.
1.
Search
Button -
Search Instruction
2. Input the address.
3. Press the
Search
Button.
Page 52
To jump to a particular
instruction.
1.
Search
Button -
Search Instruction.
2. Select the instruction.
3. Press the
Search
Button.
Page 54
To jump to a particular
instruction using a
particular address.
1.
Search
Button –
Search Instruction.
2. Select the instruction and input the
address.
3. Press the
Search
Button.
Page 54
To display the previous
program section or the
next program section.
Press the
Previous Program Section
Button or
Next Program Section
Button.
Page 57
Ladder
program
section
display
To display hidden
program lines when the
program section exceeds
the number of rows in the
ladder display area.
Use the Up Scroll Arrow and Down Scroll
Arrow Buttons to scroll up and down.
Page 57
To read I/O comments
from the PLC.
Menu
Button –
I/O Comment Reading
Page 64
To display or hide I/O
comments.
Pressing the
I/O Comments
Button
switches to 3-line display, 1-line display,
and no display in order.
Page 65
I/O
comments
To see the details of I/O
comments.
Press the desired address on the ladder
program section or Multiple I/O Monitor
once.
Page 65
