Appendix 2 Dimensions
A-15
NS12-V1/-V2, NS10-V1/-V2 Cable Connection Dimensions
NS12-V1/-V2 and NS10-V1/-V2 Video Board (NS-CA001) Mounted Dimensions
NS12-V1/-V2 and NS10-V1/-V2 Video Board (NS-CA002) Mounted Dimensions
