284
Model List Appendix J
Cables with Connectors
* The XW2Z-S001 is a converting cable. A CV500-CN228 must be purchased separately for connection to a
computer.
Connection Cable
Applicable Connectors
Printer Cable
Cable for Peripheral Port of CS/CJ-series PLC
Connecting Cable for the CPM2C Communications Connector
Model Cable Length Specification
CV500-CN228 2 m 25-pin (male) ↔ 9-pin (male)
XW2Z-S001* 15 cm 25-pin (female) ↔ 14-pin (male)
XW2Z-S002 2 m 9-pin (female) ↔ 9-pin (male)
Model Specification
AWG28×5P IFVV-SB Multicore cable, manufactured by Fujikura, Ltd.
CO-MA-VV-SB 5P×28AWG Multicore cable, manufactured by Hitachi Cable, Ltd.
Name Model Specification
Connector XM2A-2501 25-pin type (male), made by OMRON
XM2D-2501 25-pin type (female), made by OMRON (for personal computers)
XM2A-0901 9-pin type (male), made by OMRON
XM2D-0901 9-pin type (female), made by OMRON (for personal computers)
DB-25P 25-pin type (male), made by JAE
Connector hood XM2S-2511 25-pin type, mm pitch screw, made by OMRON
XM2S-2513 25-pin type, inch pitch screw, made by OMRON
XM2S-0911 9-pin type, mm pitch screw, made by OMRON
XM2S-0911-E 9-pin type, mm pitch screw, made by OMRON
XM2S-0913 9-pin type, inch pitch screw, made by OMRON
DB-C2-J9 25-pin type, made by JAE
Model Specification
NT-CNT121 Printer cable for half pitch (1.5 m), made by OMRON
Model Specification
CS1W-CN118 Made by OMRON (CS-series peripheral port ↔ D-Sub, 9-pin, female)
Model Specification
CPM2C-CN111 Made by OMRON (CPM2C communications port ↔ D-Sub, 9-pin, female, C-series periph-
eral port)
To Next Page
