61
Connecting to the RS-232C Port at the Host Section 4-1
When Using the NT Link
(1:1) Method
Compatible Host Units
Some models and series of OMRON PLCs have the NT link (1:1) function
built in. With CQM1H PLCs, a Serial Communications Board can be added to
provide 1:1 NT Link communications. Some C200HX/HG/HE(-Z)E CPU Units
can be connected by the NT link (1:1) method by installing a Communications
Board.
Check the model and series of the PLC against the type of CPU Unit before
making the connections.
The Units that can be connected to the NT31/NT31C by the NT link (1:1)
method using the RS-232C ports of both Units are indicated in the table
below.
PLC Series CPU Units with Built-in
NT Link Function
CPU Units Connectable
with Expansion Commu-
nications Board
(*1)
Connectable
to
C series C200HS-CPU21-E, -EC
C200HS-CPU23-E
C200HS-CPU31-E
C200HS-CPU33-E
--- C200HS
C200HE-CPU42-(Z)E C200HE-CPU32-(Z)E
C200HE-CPU42-(Z)E
C200HE (-Z)E
C200HG-CPU43-(Z)E
C200HG-CPU63-(Z)E
C200HG-CPU33-(Z)E
C200HG-CPU43-(Z)E
C200HG-CPU53-(Z)E
C200HG-CPU63-(Z)E
C200HG (-Z)E
C200HX-CPU44-(Z)E
C200HX-CPU64-(Z)E
X200HX-CPU65-ZE
C200HX-CPU85-ZE
C200HX-CPU34-(Z)E
C200HX-CPU44-(Z)E
C200HX-CPU54-(Z)E
C200HX-CPU64-(Z)E
C200HX-CPU65-ZE
C200HX-CPU85-ZE
C200HX (-Z)E
CPM1-10CDR-@
(*2)
CPM1-20CDR-@
(*2)
CPM1-30CDR-@
(*2)
CPM1A-10CD@-@
(*2)
CPM1A-20CD@-@
(*2)
CPM1A-30CD@-@
(*2)
CPM1A-40CD@-@
(*2)
--- CPM1
CPM2A-30CD@@-@
CPM2A-40CD@@-@
CPM2A-60CD@@-@
--- CPM2A
CPM2C-10@@@@@@-@
(*3)
CPM2C-20@@@@@@-@
(*3)
--- CPM2C
CQM1-CPU41-EV1
CQM1-CPU42-EV1
CQM1-CPU43-EV1
CQM1-CPU44-EV1
CQM1-CPU45-EV1
--- CQM1
CQM1H-CPU21-E
CQM1H-CPU51-E
CQM1H-CPU61-E
CQM1H-CPU51
(*4)
CQM1H-CPU61
(*4)
CQM1H
CV series
(*5)
CV500-CPU01-EV1 --- CV500
CV1000-CPU01-EV1 --- CV1000
CV2000-CPU01-EV1 --- CV2000
CVM1 series
(*5)
CVM1-CPU01-EV2
CVM1-CPU11-EV2
CVM1-CPU21-EV2
--- CVM1
CompoBus/S
Master Control
Unit
SRM1-C02-V1 --- SRM1
