62
Connecting to the RS-232C Port at the Host Section 4-1
*1
One of the following Communications Boards is required: C200HW-
COM02/COM04/COM05/COM06-EV1.
*2
A CPM1-CIF01 adapter is required.
*3
Use a CPM2C-CN111 or CS1W-CN114/118 Connecting Cable, CPM1-
CIF01 RS-232C Adapter, or CPM1-CIF11 RS-422A Adapter to connect.
*4
A CQM1H-SCB41 Serial Communications Board is required.
*5
CPU Units of CVM1/CV series PLCs without the suffix -EV@ cannot be
connected.
Reference: CS/CJ-series CPU Unit cannot be connected with the 1:1 connection NT link
method. Use the 1:N connection NT link method (standard or high-speed) in-
stead to make the 1:1 connection. For details, refer to Using the NT Link (1:N)
Method (page 64) or Using the High-speed NT Link (1:N) Method (page 69).
Settings at The Host
The setting methods for each Unit are as follows:
Connecting to a C-series C200HS, C200HX/HG/HE(-Z)E, CPM1, CPM2A,
CPM2C, CQM1, CQM1H, or SRM1
PLC Setup Area Settings
Write the PLC Setup area (data memory) settings directly from a Program-
ming Device (e.g. SYSMAC support software) in accordance with the host
model and port.
*1
RS-232C port of the Communications Board
*2
RS-232C port of the Serial Communications Board
For details on operations relating to the PLC Setup area, refer to the manual
for the PLC which is used.
Connecting to a CPM2C
The CPM2C PLCs do not have the same kind of port connectors found on CS/
CJ-series PLCs. The CPM2C’s communications port handles both RS-232C
and peripheral port connections which are divided internally. Therefore, when
using the CPM2C, it is necessary to select RS-232C or peripheral port con-
nections, according to the kind of cable and port (on the cable) used, as
shown in the following table. Refer to the CPM2C Operation Manual for more
details.
Host Model Word # Writing Value Setting
RS-232C port of C200HS, C200HX/
HG/HE(-Z)E, CPM2A, CPM2C,
CQM1, CQM1H, SRM1
DM6645 4000 Use NT link
(1:1)
Port A of C200HX/HG/HE(-Z)E
(*1)
Por t 1 of CQM1H
(*2)
DM6555
Port B of C200HX/HG/HE(-Z)E
(*1)
DM6550
CPM1 DM6650
Port connecting to PT PLC Setup
RS-232C port (D-Sub 9-pin) of CPM2C-CN111 Built-in RS-232C port settings
Peripheral port of CPM2C-CN111 Peripheral port settings
RS-232C port (D-Sub 9-pin) of CS1W-CN118 Built-in RS-232C port settings
Peripheral port of CS1W-CN114 Peripheral port settings
