130
Connecting to the Host’s RS-422A/485 Port
Section 5-2
When Using the NT Link (1:N) Method
Compatible host units
The OMRON PCs that can be connected using the RS-422A/485 type NT link
(1:N) method are C-series C200HX/HG/HE-ZE models only. A communication
board must be installed to make the connection.
Check the model and series of the PC against the type of CPU or communica-
tions board before making the connections.
The host units that can be connected to the RS-232C port of the NT31/NT31C by
the RS-422A type NT link (1:N) function via a convertor are indicated in the table
below.
PC
Series
CPUs with Built-in
RS-422A type
NT Link (1:1) Function
CPU that becomes
connectable by installing a
communication board
Model Name
CS1
series
CS1G-CPU42/43/44/45-E
(*1)
CS1H-CPU63/64/65/66/67-E
(*1)
CS1G
CS1H
C200HE-CPU32 (–Z)
(*2)
C200HE-CPU42 (–Z)
(*2)
C200HE (-Z)
C200HE-CPU32-(Z)E
(*1)
C200HE-CPU42-(Z)E
(*1)
C200HE-CPU32-(Z)E
(*1)
C200HE-CPU42-(Z)E
(*1)
C200HE (-ZE)
C series
C200HG-CPU33-(Z)E
(*1)
C200HG-CPU43-(Z)E
(*1)
C200HG-CPU53-(Z)E
(*1)
C200HG-CPU63-(Z)E
(*1)
C200HG-CPU33-(Z)E
(*1)
C200HG-CPU43-(Z)E
(*1)
C200HG-CPU53-(Z)E
(*1)
C200HG-CPU63-(Z)E
(*1)
C200HG (-ZE)
C200HX-CPU34-(Z)E
(*1)
C200HX-CPU44-(Z)E
(*1)
C200HX-CPU54-(Z)E
(*1)
C200HX-CPU64-(Z)E
(*1)
C200HX-CPU65-ZE
(*1)
C200HX-CPU85-ZE
(*1)
C200HX-CPU34-(Z)E
(*1)
C200HX-CPU44-(Z)E
(*1)
C200HX-CPU54-(Z)E
(*1)
C200HX-CPU64-(Z)E
(*1)
C200HX-CPU65-ZE
(*1)
C200HX-CPU85-ZE
(*1)
C200HX (-ZE)
*1 The serial CS1W-SCB41–E communication board is required.
*2 A C200HW-COM03-V1 or C200-COM06-V1 communication board is required.
Settings at the host
- C-series C200HX/HG/HE(-ZE)
[PC system setting area settings]
Write the communication conditions directly into the PC system setting area
(data memory) using a peripheral tool (e.g. SYSMAC support software).
For details on setting the PC system setting area settings, refer to the SYS-
MAC C200HX/HG/HE(-ZE) Operation Manual (W303/W322).
Make the setting indicated in the word shown below.
