Connecting to the Host’s RS-232C Port
Section 5-1
5-1-4 Recommended Connectors, Cables, and Crimp Terminals
 Connectors and cables recommended for RS-232C
When making an RS-232C connecting cable, as far as possible use the recom-
mended parts indicated in the table below. Some units come supplied with one
connector and connector hood.
Check the required parts and prepare them in advance.
Name Model Remarks Delivered with
XM2A-0901
9-pin type
Made by OMRON
CS1-series CS1G/H
C-series CQM1, C200HS,
C200HX/HG/HE(-ZE)
CVM1/CV-series CPUs
CV500-LK201
Connector
XM2A-2501
25-pin type
Made by OMRON
C500-LK203
3G2A5-LK201-EV1
C200H-LK201-V1
DB-25P
25-pin type
Made by JAE
3G2A5-LK201-EV1
3G2A6-LK201-EV1
XM2S-0911
9-pin type
Made by OMRON
C-series CQM1, C200HS,
C200HX/HG/HE(-ZE)
CVM1/CV-series CPUs
CV500-LK201
XM2S-0913 Made by OMRON 9-pin
Connector
XM2S-0911-E Made by OMRON 9-pin CS1 series CS1G/CS1H
hood
XM2S-2511
25-pin type
Made by OMRON
C500-LK203
3G2A5-LK201-EV1
C200H-LK201-V1
DB-C2-J9
25-pin type
Made by JAE
3G2A5-LK201-EV1
3G2A6-LK201-EV1
AWG28 5P
IFVV-SB
Multi-core shielded cable
Made by Fujikura, Ltd.
Cable
CO-MA-VV-SB
5P 28AWG
Multi-core shielded cable
Made by Hitachi, Ltd.
 Cables with connectors made by OMRON
When connecting an NT-AL001 and a PC, use the OMRON cables with connec-
tors indicated in the table below.
Model Cable Length Connector Specification
XW2Z-200S 2 m
9-pin ⇔ 25-pin
XW2Z-500S 5 m
9-pin
⇔
25-pin
Host link, NT link (1:1)
XW2Z-200T 2 m
9-pin ⇔ 9-pin
XW2Z-500T 5 m
9-pin
⇔
9-pin
Host link, NT link (1:1)
